PVC Coated Wire Rope

PVC Coated Wire Rope is a steel wire rope sheathed in a protective PVC layer for enhanced durability and weather resistance. It is manufactured to ASTM, DIN, and ISO standards using galvanized or stainless steel wire cores. The PVC sheath prevents abrasion and corrosion while providing a smooth, safe surface for handling and installation. Available in clear or colored coatings, it is widely used in fencing, marine, sports equipment, construction, and general rigging. This rope combines strength, flexibility, and long service life, making it suitable for both indoor and outdoor applications.

Add to quote
Category: Tags: ,
Description

Premium Quality PVC Coated Wire Rope Supplier in Dubai, UAE

Unifastener Industries LLC is a reliable supplier and manufacturer of premium-quality PVC Coated Wire Ropes in Dubai, UAE. The company specializes in industrial fastening, lifting accessories, rigging hardware, and wire rope solutions designed for construction, marine, fencing, industrial, and architectural applications. PVC Coated Wire Rope consists of a high-strength steel wire rope covered with a durable PVC coating that provides enhanced protection against corrosion, abrasion, moisture, and environmental exposure. The coating also improves safety, handling comfort, and the overall lifespan of the wire rope. Manufactured using high-grade materials and advanced production standards, PVC Coated Wire Ropes deliver excellent tensile strength, flexibility, weather resistance, and long-term reliability in demanding working conditions.


Standards:
– ASTM A1023 / A1023M (general wire ropes)
– ASTM A603 (zinc-coated steel wire strand)
– DIN 3055 (wire ropes – specifications)
– DIN 3056 (wire rope with plastic coating)
– ISO 2408 (steel wire ropes for general purposes)

Grades:
– High tensile carbon steel
– Stainless steel A2 / A4 (AISI 304 / 316 for marine/corrosive environments)

Material Options:
– Inner rope: carbon steel (bright, galvanized) or stainless steel
– Outer sheath: PVC (polyvinyl chloride, UV stabilized)

Size Range:
– Rope diameter (core): 2mm to 16mm
– Overall diameter with PVC: 3mm to 20mm
– Constructions: 6×7, 6×19, 7×19, etc.

Types:
– Galvanized steel core with PVC coating
– Stainless steel core with PVC coating
– Clear PVC sheath
– Colored PVC sheath (green, black, white, or custom RAL)

Properties:
– PVC sheath protects wire rope from moisture, abrasion, and corrosion
– Inner rope provides high tensile strength and flexibility
– Available with fiber core (FC) or steel wire core (IWRC)
– Smooth PVC surface prevents damage to surrounding materials

Coating Options:
– PVC coating (clear, black, green, white, or custom colors)
– Inner rope galvanized (ASTM A153 / DIN EN ISO 1461)
– Stainless steel natural finish

Add-ons:
– Can be supplied with thimbles, ferrules, and clamps
– Pre-fabricated PVC-coated slings available
– Certification/load capacity test reports available on request
