Gun Nail with Steel / PVC Washer

Gun Nails with Steel or PVC Washers are fastening solutions designed for use with direct fastening tools in concrete, masonry, and steel. They are manufactured to ASTM, DIN, and ISO standards in carbon steel or stainless steel with steel or PVC washers. The washer increases the holding surface, preventing pull-through and providing stronger, safer fixings. Steel washer versions are used for heavy-duty applications, while PVC washer types are common for insulation fixing. They are widely used in construction, HVAC, insulation works, and general fastening applications.

Add to quote
Category: Tags: ,
Description

Premium Quality Gun Nail with Steel / PVC Washer Supplier in Dubai, UAE

Unifastener Industries LLC is a reliable supplier and manufacturer of premium-quality Gun Nails with Steel and PVC Washers in Dubai, UAE. The company specializes in fastening systems, insulation fixings, construction hardware, and industrial fastening solutions designed for fast and secure installations. Gun Nails with Steel or PVC Washers are specifically designed for use with powder-actuated and gas-actuated fastening tools. The attached washer provides increased holding area and load distribution, making these fasteners ideal for securing insulation boards, roofing membranes, waterproofing materials, cladding systems, and lightweight construction components. Manufactured using high-strength steel and durable washer materials, these fasteners offer superior penetration, excellent holding power, corrosion resistance, and long-term reliability in demanding construction environments.

Standards:
– ASTM A510 (carbon steel wire for nails)
– ASTM A153 (zinc coating for hot-dip galvanized fasteners)
– DIN 1151 (nail specifications)
– DIN EN ISO 1461 (galvanized coating standards)
– ISO 9001 (manufacturing quality compliance)

Grades:
– Carbon steel (heat-treated for hardness)
– Stainless steel AISI 304 / 316 (corrosion-resistant applications)

Material Options:
– Nail: carbon steel (plain, galvanized, or hardened)
– Washer: carbon steel (zinc plated, hot-dip galvanized) or PVC (rigid, UV stabilized)

Size Range:
– Nail shank diameter: 2.5mm to 5mm
– Nail length: 25mm to 100mm
– Washer diameter: 20mm to 40mm

Types:
– Steel washer gun nail
– PVC washer gun nail
– Hot-dip galvanized washer gun nail
– Stainless steel washer gun nail

Properties:
– Designed for fast installation using direct fastening guns
– Washer provides larger bearing area to prevent pull-through
– Ensures firm fixing in concrete, masonry, and steel
– Available with either rigid PVC washer for insulation or steel washer for strength

Coating Options:
– Zinc electroplated nail and washer
– Hot-dip galvanized (ASTM A153 / DIN EN ISO 1461)
– Black oxide finish (special request)
– Stainless steel polished finish

Add-ons:
– Available collated for use in fastening tools
– Bulk contractor packs or retail packs supplied
– Certification/pull-out test reports available on request
